Pinball: A Cryogenic CMOS Predecoder for Scalable Quantum Error Correction Under Realistic Noise In Plain English: Quantum computers are extremely sensitive to errors caused by heat and electrical noise, so they need constant error checking to work properly. This error checking creates a huge amount of data that must be sent from the super-cold quantum chip to room-temperature computers for processing, which uses a lot of power and slows things down. The researchers created a tiny, energy-efficient helper chip that works at the same ultra-cold temperature as the quantum processor and handles the most common errors right there. This reduces the amount of data needing transmission by thousands of times and cuts power use dramatically, making it much more feasible to build large-scale quantum computers in the future. Summary: The paper presents Pinball, a cryogenic predecoder implemented in CMOS for quantum error correction (QEC) that operates under realistic circuit-level noise conditions. As quantum computers scale toward millions of qubits, the communication and power demands of transmitting raw syndrome data to room-temperature decoders become prohibitive. While prior work proposed cryogenic predecoding, it often neglected full noise modeling or relied on non-CMOS technologies like Single Flux Quantum (SFQ) logic, limiting accuracy and optimization potential. Pinball addresses these limitations by integrating detailed circuit-level noise analysis—accounting for error generation and propagation across QEC circuits—into a lightweight CMOS design optimized for operation at 4 K using 22 nm FDSOI technology. By handling frequent, sparse errors directly in the cryogenic environment, Pinball drastically reduces the volume of syndrome data requiring transmission, achieving up to a 3780.72× reduction in bandwidth. More importantly, it improves logical error rate (LER) performance by nearly six orders of magnitude compared to existing cryogenic predecoders. Even when compared to room-temperature (RT) predecoders and ensemble configurations, Pinball reduces LER by 32.58× and 5×, respectively, despite stricter power and area constraints. Power efficiency is further enhanced through voltage/frequency scaling and body biasing, enabling 22.2× lower typical power consumption and up to 67.4× total energy savings. With a peak power under 0.56 mW, and assuming a 4 K power budget of 1.5 W, Pinball can support up to 2,668 logical qubits at code distance d=21, demonstrating its viability for large-scale fault-tolerant quantum computing systems. Key Points: - Pinball is a cryogenic CMOS predecoder designed for real-time quantum error correction under circuit-level noise. - It significantly outperforms prior cryogenic predecoders, reducing logical error rates by nearly six orders of magnitude. - Compared to room-temperature predecoders, Pinball reduces LER by 32.58× and 5× versus single and ensemble RT configurations. - Syndrome data bandwidth is reduced by up to 3780.72×, alleviating communication bottlenecks. - Implemented in 4 K-characterized 22 nm FDSOI CMOS, enabling architecture-technology co-optimization. - Peak power consumption is under 0.56 mW, with 22.2× lower typical power via voltage/frequency scaling and body biasing. - Total energy savings reach up to 67.4× compared to baseline systems. - Supports up to 2,668 logical qubits at d=21 within a 1.5 W cryogenic power budget. Notable Quotes: - "Our design achieves higher predecoding accuracy, outperforming logical error rates (LER) of the current state-of-the-art cryogenic predecoder by nearly six orders of magnitude." - "By increasing cryogenic coverage, we also reduce syndrome bandwidth up to 3780.72x." - "Through co-design with 4 K-characterized 22 nm FDSOI technology, we achieve a peak power consumption under 0.56 mW." - "Voltage/frequency scaling and body biasing enable 22.2x lower typical power consumption, yielding up to 67.4x total energy savings." - "Assuming a 4 K power budget of 1.5 W, our predecoder supports up to 2,668 logical qubits at d=21." Data Points: - Logical error rate (LER) improvement: nearly six orders of magnitude (10⁶×) over prior cryogenic predecoder. - LER reduction: 32.58× better than state-of-the-art RT predecoder - 5× better than RT ensemble. - Syndrome bandwidth reduction: up to 3780.72×. - Peak power consumption: under 0.56 mW. - Typical power reduction: 22.2× lower via voltage/frequency scaling and body biasing. - Total energy savings: up to 67.4×. - Technology node: 22 nm FDSOI. - Operating temperature: 4 K. - Supported logical qubits: up to 2,668 at code distance d=21. - Cryogenic power budget assumed: 1.5 W. Controversial Claims: - The claim that Pinball reduces logical error rates by nearly six orders of magnitude compared to the state-of-the-art cryogenic predecoder may depend heavily on specific noise models and assumptions about error sparsity - real-world performance could vary significantly if error distributions differ. - The assertion that cryogenic CMOS can outperform room-temperature ensemble decoders in LER while operating under strict power constraints challenges conventional wisdom about computational capability at low temperatures and may require independent validation. - The scalability projection of supporting 2,668 logical qubits assumes ideal integration and thermal management at 4 K, which may not reflect practical engineering limits in multi-layer quantum systems. Technical Terms: - Quantum Error Correction (QEC) - Cryogenic predecoder - Circuit-level noise - Logical Error Rate (LER) - Syndrome bandwidth - Single Flux Quantum (SFQ) logic - 22 nm FDSOI CMOS - Voltage/frequency scaling - Body biasing - Architecture-technology co-optimization - Surface code (implied by code distance d=21) - Code distance (d) - Fault-tolerant quantum computing - Cryogenic CMOS - 4 K operation - Ensemble decoding - Error propagation - Data processing overhead - Power-constrained computing —Ada H. Pemberley Dispatch from The Prepared E0
